Twin Fractal Harps with voice pitch to MIDI (howling)
improvisation
Flying" -
Fractal Harp Rig - Matt Spencer on Drums"
This piece features some amazing drumming from
Matt Spencer. I'm really honored to have him
lend his talent here and hope to work with him
more in the future.
I don't explain refinements to my crazy Fractal
Harp rig much when I post stuff I do but I
thought I might give it a try. There's a lot
going on here.
The main (attached) harp here features my stock
pivoting slide that controls the relative pitch
of all of the strings on the instrument. The
harp also has a string tension/bend pedal that
independently bends the pitch of certain strings
in varying increments like that of a standard
pedal steel guitar. Each string also has it's
own independent MIDI trigger while sensors
embedded in the slide and bend pedal allow the
MIDI output to mirror the actual pitch of each
string. My right foot is planted on the string
tension pedal that also doubles as a MIDI bend
pedal and locks with the effected strings
outputs mirroring it's function to MIDI. My left
foot simultaneously controls a separate MIDI
sustain pedal that determines all the harp
notes' duration functioning like a piano's
sustain pedal.
My right
foot sits atop a combination wha-wha/cable
driven harp pitch pedal comprised of an extra wide
platform that straddles several MIDI CC and analog
pedals that work in unison. String tension cable
mechanisms extend up to both harps from the same
setup. The copper contacts on the right side of
my right foot are parts of an additional
sub-pedal momentary switch that chooses between
microphone vocal and pitch to MIDI "Howler"
vocals. My left foot is planted on a sustain
pedal that functions for sustain for all
keyboard and harp notes with another nearby
momentary switch pressure zone that switches on
vocal/echo/FXs
I've built
upon these MIDI functions recently and set up
the individual string MIDI outputs into multi-timbrel
and instantly switchable tuning schemes. This
enables multiple harmonized MIDI voices per
string that function across the harps entire
range. These control several instruments sounds
stacked in separate turnings and synchronous
harmony. This setup provides the ability to
spontaneously emit rapid phrases from harp
sweeps utilizing the ability to set various MIDI
voices in legato/mono modes. These are
illustrated with rapid bass, guitar and piano
like phrases created by sweeps across the harp
and demonstrated here in this video.
Above
left: Piezo triggers mounted on the back
side of the pivot slide (non active area )
convert string vibration into MIDI notes that
match or harmonize each individual
strings analog output . A sensor built into the
slide matches the variable pitch of each string
while a the pedal additionally manipulates the
pitch of selective strings to additional
intervals.
Another sleazy development here is that the root
relative tonality of the harp string pitches can
now be dictated from the bass guitar (with and
beyond the pivoting slide). The customized old
Peavey Midibase MIDI capable bass features my
side string thumb clutch system I'm continuing
to develop. When the thumb string is squeezed
and pressed against the metal contact on the
side of the neck, it acts as a clutch expanding
the capability of notes simultaneously played on
other bass strings. In the video here, I'm
triggering simple, big stupid tonic power chords
using the bass clutch WHILE dictating that same
root key tonality to the entire harp. You can
get an idea of what I'm describing by watching
the crazy chromatic sections of the piece or
following it's relatively basic chord structure
and seeing how clutched bass notes cause harp
phrases travel through various root turnings.
The harp on the left used in some sections of
the tune in the video above here is my famous/original/classic
Fractal Harp with a similar hybrid MIDI
expansion added. It functions mostly like the
main harp described above, but it's relative
string pitch is dictated entirely by the
pivoting slide (independently of the bass
guitar). This harp features a solid maple body
and telecaster pickups. It shares the same pedal
system with split pedal functionality
accommodating both harps.
Above &
below My original
Fractal Harp in various stages
of twisted & sick experimentation.
The high pitch melodic/lead sound here is sung
"howled" and performed in tandem with the harp
and bass. The headset mic picks up my vocal and
routed into a real-time pitch to MIDI converter.
This allows me to sing feedback and guitar
sounds that I've developed over the
years on the fly.
All the non-organic (MIDI triggered) sounds you
hear produced by the devices I'm playing in this
video are all coming from custom instruments
I've created in a software program called
Kontakt made by Native Instruments.
